Basic Info
Model No.: NUP2307E
Product Description
Model NO.: NUP2307E The Number of Rows: Single Material: Bearing Steel Load Direction: Radial Bearing Precision: P0 P5 P6 Roller Super Finishing: Yes Application: Vehicles Transport Package: Standard Exporting Packing Origin: China Rolling Body: Roller Bearings Outer Dimension: Small and Medium-Sized (60-115mm) Spherical: Non-Aligning Bearings Separated: Separated Roller Convexity: Yes Raceway Super Finishing: Yes Trademark: HECTO or OEM or neutral marking or no marking Specification: 35 HS Code: 84825000
Why Choose HECTO?
1. More than 20 years of manufacturing and exporting experiences
2. an ISO/TS16949 company
3. 100% inspecting of products
4. More competitive prices with better quality
5. More than 99% of delivery in time
6. Rapid response of your emails and questions
7. Products can be traced back
Cylindrical Roller Bearing
Contact us if you need more details on Roller Bearing. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Auto Bearing、Short Cylindrical Roller Bearing. If these products fail to match your need, please contact us and we would like to provide relevant information.
| Basic Features of Cylindrical Roller Bearing | |
| Types | N series NU series NF series NJ series NUP series NCL series RN series RNU series Full complement series Double row series |
| Material | Bearing Steel(GCr15, 100Cr6) 08/10 SPCC Bronze Nylon |
| Dimension | Metric and Inch |
| Precision | P0 P5 P6 |
| Super finishing | Yes |
| Single and double row | Both single row and double row |
| Dimension Range | 15mm~200mm(bore diameter) |
| MOQ | 1 PC |
| Delivery Time | 30-60 days |
| Sea Ports | Shanghai Ningbo Qingdao |
Why Choose HECTO?
1. More than 20 years of manufacturing and exporting experiences
2. an ISO/TS16949 company
3. 100% inspecting of products
4. More competitive prices with better quality
5. More than 99% of delivery in time
6. Rapid response of your emails and questions
7. Products can be traced back
Cylindrical Roller Bearing
| Shaft | Bearing No. | Boundary Dimensions(mm) | Basic Load Ratings(N) | Limiting Speed | |||
| d | D | B | Cr | Cor | Oil(RPM) | ||
| 17 | N203 | 17 | 40 | 12 | 11400 | 9100 | 19000 |
| NJ203 | 17 | 40 | 12 | 11400 | 9100 | 19000 | |
| NJ203ETN | 17 | 40 | 12 | 16900 | 13800 | 19000 | |
| NU203 | 17 | 40 | 12 | 11400 | 9100 | 19000 | |
| NU203ETN | 17 | 40 | 12 | 16900 | 13800 | 19000 | |
| NJ2203E | 17 | 40 | 16 | 22800 | 20300 | 16400 | |
| 20 | N204 | 20 | 47 | 14 | 15800 | 13100 | 16400 |
| NF204 | 20 | 47 | 14 | 15800 | 13100 | 16400 | |
| NJ204 | 20 | 47 | 14 | 17000 | 14400 | 16400 | |
| NU204 | 20 | 47 | 14 | 15800 | 13100 | 16400 | |
| N304 | 20 | 52 | 15 | 21800 | 17700 | 13800 | |
| NJ304 | 20 | 52 | 15 | 21800 | 17700 | 13800 | |
| NU304 | 20 | 52 | 15 | 21800 | 17700 | 13800 | |
| NUP304ETN | 20 | 52 | 15 | 31500 | 26800 | 13100 | |
| NJ2304ETN | 20 | 52 | 21 | 42000 | 38700 | 13000 | |
| 25 | N205 | 25 | 52 | 15 | 17000 | 14900 | 13800 |
| NF205 | 25 | 52 | 15 | 17000 | 14900 | 13800 | |
| NJ205 | 25 | 52 | 15 | 17000 | 14900 | 13800 | |
| NJ205E | 25 | 52 | 15 | 29900 | 28400 | 13100 | |
| NJ205ETN | 25 | 52 | 15 | 29900 | 28400 | 13100 | |
| NU205 | 25 | 52 | 15 | 17000 | 14900 | 13800 | |
| NU205/C3 | 25 | 52 | 15 | 15400 | 14900 | 13800 | |
| NU205E | 25 | 52 | 15 | 29900 | 28400 | 13100 | |
| NU205ETN | 25 | 52 | 15 | 29900 | 28400 | 13100 | |
| NUP205 | 25 | 52 | 15 | 17000 | 14900 | 13800 | |
| NCL205 | 25 | 52 | 15 | 24600 | 24300 | 13100 | |
| N2205 | 25 | 52 | 18 | 24100 | 23300 | 13100 | |
| NJ2205 | 25 | 52 | 18 | 24100 | 23300 | 13100 | |
| NU2205 | 25 | 52 | 18 | 24100 | 23300 | 13100 | |
| NU2205/C3 | 25 | 52 | 18 | 21400 | 22800 | 13100 | |
| NU2205EV | 25 | 52 | 18 | 41400 | 43300 | 11400 | |
| N305 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| N305ENTN/C3 | 25 | 62 | 17 | 41500 | 37400 | 11400 | |
| NF305 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NJ305 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NJ305/C3 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NJ305E | 25 | 62 | 17 | 41500 | 37400 | 11400 | |
| NJ305ETN | 25 | 62 | 17 | 41500 | 37400 | 10500 | |
| NU305 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NUP305 | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NUP305E | 25 | 62 | 17 | 41500 | 37400 | 10500 | |
| NUP305N | 25 | 62 | 17 | 29100 | 25200 | 11400 | |
| NCL305 | 25 | 62 | 17 | 39500 | 37800 | 10500 | |
| NU2305E | 25 | 62 | 24 | 57000 | 56100 | 4500 | |
| NJ2305E | 25 | 62 | 24 | 57000 | 56100 | 9200 | |
| NJ2305EV/C4 | 25 | 62 | 24 | 66300 | 69700 | 9200 | |
| NJ2305VH | 25 | 62 | 24 | 63000 | 57000 | 4500 | |
| NUP2305E | 25 | 62 | 24 | 57000 | 56100 | 9200 | |
| NCL2305 | 25 | 62 | 24 | 57700 | 61400 | 9200 | |
| 30 | N206 | 30 | 62 | 16 | 23900 | 22200 | 11300 |
| N206E | 30 | 62 | 16 | 36800 | 34400 | 10500 | |
| NJ206 | 30 | 62 | 16 | 23900 | 22200 | 11300 | |
| NJ206E | 30 | 62 | 16 | 39100 | 37300 | 10500 | |
| NJ206ETN | 30 | 62 | 16 | 39100 | 37300 | 10500 | |
| NU206 | 30 | 62 | 16 | 23900 | 22200 | 11300 | |
| NU206E | 30 | 62 | 16 | 39100 | 37300 | 10500 | |
| NUP206E | 30 | 62 | 16 | 39100 | 37300 | 10500 | |
| NUP206E/C4 | 30 | 62 | 16 | 39100 | 37300 | 10500 | |
| NCL206 | 30 | 62 | 16 | 33800 | 35100 | 10500 | |
| NJ2206ETN | 30 | 62 | 20 | 48900 | 49800 | 10500 | |
| NJ2206E | 30 | 62 | 20 | 48900 | 49800 | 10500 | |
| NJ2206E.TVP | 30 | 62 | 20 | 48900 | 49800 | 5000 | |
| N306 | 30 | 72 | 19 | 35900 | 31900 | 9200 | |
| NJ306 | 30 | 72 | 19 | 35900 | 31900 | 9200 | |
| NJ306E | 30 | 72 | 19 | 53200 | 50200 | 8500 | |
| NJ306E/C3 | 30 | 72 | 19 | 53200 | 50200 | 8500 | |
| NU306 | 30 | 72 | 19 | 35900 | 31900 | 9200 | |
| NU306E | 30 | 72 | 19 | 53200 | 50200 | 9200 | |
| NU306MN/P63 | 30 | 72 | 19 | 35100 | 38600 | 9200 | |
| NUP306 | 30 | 72 | 19 | 35900 | 31900 | 9200 | |
| NFP306 | 30 | 72 | 19 | 35900 | 31900 | 9200 | |
| 35 | N207 | 35 | 72 | 17 | 31400 | 28900 | 9900 |
| NF207 | 35 | 72 | 17 | 31400 | 28900 | 9900 | |
| NJ207 | 35 | 72 | 17 | 31400 | 28900 | 9900 | |
| NJ207E | 35 | 72 | 17 | 50200 | 50100 | 9200 | |
| NU207 | 35 | 72 | 17 | 31400 | 28900 | 9900 | |
| NUP207 | 35 | 72 | 17 | 31400 | 28900 | 9900 | |
| NU2207E | 35 | 72 | 23 | 61600 | 65200 | 4300 | |
| NJ2207E | 35 | 72 | 23 | 61600 | 65200 | 7900 | |
| NUP2207E | 35 | 72 | 23 | 61600 | 65200 | 7900 | |
| N307 | 35 | 80 | 21 | 46400 | 43000 | 9200 | |
| NF307 | 35 | 80 | 21 | 46400 | 43000 | 9200 | |
| NJ307 | 35 | 80 | 21 | 46400 | 43000 | 9200 | |
| NJ307/C3 | 35 | 80 | 21 | 46400 | 43000 | 3400 | |
| NJ307E | 35 | 80 | 21 | 66500 | 65300 | 7900 | |
| NU307 | 35 | 80 | 21 | 46400 | 43000 | 9200 | |
| NU307EV1 | 35 | 80 | 21 | 71000 | 71000 | 7900 | |
| NUP307E | 35 | 80 | 21 | 66500 | 65300 | 7900 | |
| NUP307EN | 35 | 80 | 21 | 66500 | 65300 | 7900 | |
| NUP307EV | 35 | 80 | 21 | 77500 | 79800 | 7900 | |
| NUP307EV/C3 | 35 | 80 | 21 | 77500 | 79800 | 7900 | |
| NJ2307E | 35 | 80 | 31 | 93000 | 100500 | 7900 | |
| NU2307EV4 | 35 | 80 | 31 | 99000 | 109000 | 7900 | |
| 40 | N208 | 40 | 80 | 18 | 43700 | 42900 | 8700 |
| NF208 | 40 | 80 | 18 | 43700 | 42900 | 8700 | |
| NJ208 | 40 | 80 | 18 | 43700 | 42900 | 8700 | |
| NU208 | 40 | 80 | 18 | 43700 | 42900 | 8700 | |
| NUP208 | 40 | 80 | 18 | 43700 | 42900 | 8700 | |
| NUP208/P6 | 40 | 80 | 18 | 43700 | 42900 | 8700 | |
| NU2208E | 40 | 80 | 23 | 72300 | 77600 | 3800 | |
| NJ2208E | 40 | 80 | 23 | 72300 | 77600 | 7900 | |
| NJ2208EV | 40 | 80 | 23 | 84700 | 95100 | 7400 | |
| N308 | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NF308 | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NF308M/P6 | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NJ308 | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NJ308ETN | 40 | 90 | 23 | 83200 | 81500 | 3000 | |
| NJ308/C3 | 40 | 90 | 23 | 58600 | 56900 | 3000 | |
| NU308 | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NUP308E | 40 | 90 | 23 | 82200 | 80300 | 7400 | |
| NUP308N | 40 | 90 | 23 | 58600 | 56900 | 7900 | |
| NUP308EN | 40 | 90 | 23 | 82200 | 80300 | 7400 | |
| NUP308ENV | 40 | 90 | 23 | 97200 | 101000 | 7000 | |
| NJ2308E | 40 | 90 | 33 | 113200 | 121100 | 7000 | |
| NUP2308E | 40 | 90 | 33 | 121000 | 140700 | 3000 | |
| 45 | N209 | 45 | 85 | 19 | 45900 | 46900 | 8500 |
| NF209 | 45 | 85 | 19 | 45900 | 46900 | 8500 | |
| NF209/C3 | 45 | 85 | 19 | 45900 | 46900 | 8500 | |
| NF209E | 45 | 85 | 19 | 63000 | 66400 | 7900 | |
| NJ209 | 45 | 85 | 19 | 45900 | 46900 | 8500 | |
| NJ209E | 45 | 85 | 19 | 63000 | 66400 | 7900 | |
| NJ209ECP | 45 | 85 | 19 | 63000 | 66400 | 8500 | |
| NU209 | 45 | 85 | 19 | 45900 | 46900 | 8500 | |
| NUP2209E | 45 | 85 | 23 | 76000 | 84500 | 7900 | |
| NUP2209EN | 45 | 85 | 23 | 76000 | 84500 | 7900 | |
| N309 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NF309 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NF309M/P6 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NJ309 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NJ309E | 45 | 100 | 25 | 99200 | 101000 | 6000 | |
| NU309 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NU309E | 45 | 100 | 25 | 99200 | 101000 | 6000 | |
| NUP309 | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NUP309N | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NUP309NR | 45 | 100 | 25 | 72900 | 69900 | 7000 | |
| NUP309EN | 45 | 100 | 25 | 99200 | 101000 | 6000 | |
| NUP309ENTN | 45 | 100 | 25 | 99200 | 101000 | 6000 | |
| NJ2309E | 45 | 100 | 36 | 138800 | 155700 | 6000 | |
| NU2309E | 45 | 100 | 36 | 138800 | 155700 | 6000 | |
| 50 | N210 | 50 | 90 | 20 | 48100 | 50900 | 7900 |
| NF210 | 50 | 90 | 20 | 48100 | 50900 | 7900 | |
| NF210C3 | 50 | 90 | 20 | 48100 | 50900 | 7900 | |
| NF210E | 50 | 90 | 20 | 65900 | 71800 | 7300 | |
| NJ210 | 50 | 90 | 20 | 48100 | 50900 | 7900 | |
| NJ210E | 50 | 90 | 20 | 65900 | 71800 | 7900 | |
| NU210 | 50 | 90 | 20 | 48100 | 50900 | 7900 | |
| NU210/P6 | 50 | 90 | 20 | 48100 | 50900 | 7900 | |
| NU210ETN/C3 | 50 | 90 | 20 | 65900 | 71800 | 7900 | |
| NUP210EN | 50 | 90 | 20 | 65900 | 71800 | 7900 | |
| NUP210E | 50 | 90 | 20 | 65900 | 71800 | 7900 | |
| NJ2210ETN | 50 | 90 | 23 | 79500 | 91500 | 3300 | |
| NUP2210E | 50 | 90 | 23 | 79500 | 91500 | 7300 | |
| N310 | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NF310 | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NJ310 | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NJ310E | 50 | 110 | 27 | 112100 | 116000 | 6000 | |
| NJ310N | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NU310 | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NUP310 | 50 | 110 | 27 | 88900 | 88800 | 6300 | |
| NUP310NV | 50 | 110 | 27 | 128200 | 144700 | 6300 | |
| NUP310ENV/C3 | 50 | 110 | 27 | 128200 | 144700 | 6000 | |
| NCL310 | 50 | 110 | 27 | 111300 | 122300 | 6300 | |
| N410 | 50 | 130 | 31 | 132300 | 127600 | 6300 | |
| NJ410 | 50 | 130 | 31 | 132300 | 127600 | 6300 | |
| 55 | N211 | 55 | 100 | 21 | 57900 | 62200 | 7100 |
| NF211 | 55 | 100 | 21 | 57900 | 62200 | 7100 | |
| NF211E | 55 | 100 | 21 | 86100 | 98700 | 6500 | |
| NJ211 | 55 | 100 | 21 | 57900 | 62200 | 7100 | |
| NJ211/C3 | 55 | 100 | 21 | 50200 | 32000 | 7100 | |
| NJ211E | 55 | 100 | 21 | 86100 | 98700 | 6500 | |
| NJ211ECP | 55 | 100 | 21 | 86100 | 98700 | 6500 | |
| NU211 | 55 | 100 | 21 | 57900 | 62200 | 7100 | |
| NU211E | 55 | 100 | 21 | 86100 | 98700 | 6500 | |
| NUP211 | 55 | 100 | 21 | 57900 | 62200 | 7100 | |
| NUP211E | 55 | 100 | 21 | 86100 | 98700 | 6500 | |
| NJ2211E | 55 | 100 | 25 | 101200 | 121500 | 3000 | |
| NJ2211E/C3 | 55 | 100 | 25 | 101200 | 121500 | 6500 | |
| NUP2211EN/C3 | 55 | 100 | 25 | 101200 | 121500 | 6500 | |
| NF311E | 55 | 120 | 29 | 138100 | 144300 | 5300 | |
| NF311E/C3 | 55 | 120 | 29 | 140500 | 147600 | 5300 | |
| NJ311E | 55 | 120 | 29 | 138100 | 144300 | 5300 | |
| NUP311EN | 55 | 120 | 29 | 140500 | 147600 | 5300 | |
| NUP311ENV/C3 | 55 | 120 | 29 | 153800 | 165700 | 5300 | |
| 60 | N212 | 60 | 110 | 22 | 71800 | 79800 | 6500 |
| NJ212 | 60 | 110 | 22 | 71800 | 79800 | 6500 | |
| NJ212E | 60 | 110 | 22 | 96200 | 105600 | 6000 | |
| NU212 | 60 | 110 | 22 | 71800 | 79800 | 6500 | |
| NU212ETN/C3 | 60 | 110 | 22 | 96200 | 105600 | 6000 | |
| NUP212E | 60 | 110 | 22 | 96200 | 105600 | 6000 | |
| NF312 | 60 | 130 | 31 | 124800 | 127800 | 5400 | |
| NF312E | 60 | 130 | 31 | 153100 | 162100 | 4900 | |
| NF312E/C3 | 60 | 130 | 31 | 153500 | 164600 | 4900 | |
| NU312E | 60 | 130 | 31 | 135900 | 96000 | 4900 | |
| NJ312E | 60 | 130 | 31 | 153100 | 162100 | 4900 | |
| NUP312ENV/C3 | 60 | 130 | 31 | 185400 | 195200 | 4900 | |
| N2312E | 60 | 130 | 46 | 225500 | 266700 | 5000 | |
| NJ2312E | 60 | 130 | 46 | 225500 | 266700 | 5000 | |
| 65 | N213 | 65 | 120 | 23 | 78800 | 87000 | 6000 |
| NF213 | 65 | 120 | 23 | 78800 | 87000 | 6000 | |
| NJ213 | 65 | 120 | 23 | 78800 | 87000 | 6000 | |
| NJ213E | 65 | 120 | 23 | 109900 | 122300 | 5400 | |
| NU213 | 65 | 120 | 23 | 78800 | 87000 | 6000 | |
| NUP213E | 65 | 120 | 23 | 109900 | 122300 | 6000 | |
| NUP213EN/C4 | 65 | 120 | 23 | 109900 | 122300 | 5400 | |
| NU313E | 65 | 140 | 33 | 182800 | 194800 | 4700 | |
| NJ313E | 65 | 140 | 33 | 182800 | 195300 | 4700 | |
| NJ313E/C2 | 65 | 140 | 33 | 182800 | 194800 | 4700 | |
| NUP313ENV | 65 | 140 | 33 | 212900 | 244900 | 4700 | |
| 70 | N214 | 70 | 125 | 24 | 82100 | 93500 | 5700 |
| NF214 | 70 | 125 | 24 | 82100 | 93500 | 5700 | |
| NF214E/C3 | 70 | 125 | 24 | 123600 | 144500 | 5700 | |
| NF214E/YB2 | 70 | 125 | 24 | 121000 | 140700 | 5400 | |
| NJ214 | 70 | 125 | 24 | 82100 | 93500 | 5700 | |
| NJ214E | 70 | 125 | 24 | 121000 | 140700 | 5400 | |
| NU214 | 70 | 125 | 24 | 82100 | 93500 | 5700 | |
| NUP214E | 70 | 125 | 24 | 121000 | 140700 | 5400 | |
| NF314E | 70 | 150 | 35 | 207100 | 226000 | 4400 | |
| NU314E | 70 | 150 | 35 | 207100 | 226000 | 4400 | |
| NJ314E | 70 | 150 | 35 | 207100 | 226000 | 4400 | |
| NJ314E/C9 | 70 | 150 | 35 | 207100 | 226000 | 4400 | |
| NUP314ENM | 70 | 150 | 35 | 236300 | 253300 | 4400 | |
| NJ2314VH | 70 | 150 | 51 | 335000 | 455000 | 4400 | |
| 75 | N215 | 75 | 130 | 25 | 95100 | 108900 | 5400 |
| NF215 | 75 | 130 | 25 | 95100 | 108900 | 5400 | |
| NJ215 | 75 | 130 | 25 | 95100 | 108900 | 5400 | |
| NU215 | 75 | 130 | 25 | 95100 | 108900 | 5400 | |
| NU215E | 75 | 130 | 25 | 132200 | 160500 | 5000 | |
| 80 | N216 | 80 | 140 | 26 | 118600 | 141600 | 5000 |
| NJ216 | 80 | 140 | 26 | 108500 | 125900 | 5000 | |
| NU216 | 80 | 140 | 26 | 118600 | 141600 | 5000 | |
| 85 | NJ217 | 85 | 150 | 28 | 122800, | 144000 | 4700 |
Roller bearing classification overview
Bearings can be divided into several types. The more popular rollers are: cylindrical rollers, tapered bearings, needle rollers and so on. What are the major categories of bearing rollers? I will explain the relevant knowledge to you, and I hope to help you. The bearing roller classification knowledge is as follows: 1....
Industrial Bearing OEM Spherical Roller Bearing (23226)
Model NO.: 23226 Separated: Unseparated Bearing Material: Bearing Steel Packing: Small Plastic Bag+Single Box+Big Plastic Bag+Big C Vibration: V1 V2 V3 V4 Certisificate: Is09000-2008 Tolerance: ABEC-1, ABEC-2 Sample: Available OEM Service: Support Trademark: BXY OR OEM Transport Package: Single Box+Outer Carton+Pallets...
Transmission Bearings Car Parts Lm11749/10 Tapered Roller Bearing
Model NO.: LM11749/10 Separated: Separated No. of Rows: Single Row Rollers: Super Finishing Rollers Size: Metric / Inch Size Structure: Bearings Cups and Cones Price: Competitive Price Quality: Good /High Quality Sample: Free Sample Available Seals Type: Open Service: OEM Trademark: CHIK TIMKEN SKF KOYO NSK Transport...
Single Row Metric Tapered Roller Bearing for Oil and Gas Industry (32017)
Model NO.: 32017 Separated: Unseparated Structure: Inch Roller Bearing Production Capacity: 100, 000 /Month Certificate: ISO9001 Sample: Free Shipping: by Ocean/Air/Road; International Express Trademark: SKF NTN NACHI NSK KOYO CHIK OEM Transport Package: Industrial Package; Single Box Package Specification: 85*130*29mm...
Product Categories : Cylindrial Roller Bearing
Email to this supplier
