L-Ball Joint Rod End Spherical Plain Bearing Sq12c Sq16c

Model NO.: SQ12C Structure: To The Heart Load Direction: Radial Spherical Plain Bearing Outer Structure: Whole Outer Ring Thickness: 20mm Application: Engineering Hydraulic Cylinder, Forging Machine, Construction Machinery, Automation Equipment, Automobile Shock Absorber, Water Conservancy Machinery Trademark: HECTO or OEM or neutral marking or no marking Specification: Joint Bearing HS Code: 84828000 Rolling Element: Single Row Material: Bearing Steel Add Lubricant: Self-lubricating Rod End: Rod End Model: Sq Precision: P0 P5 P6 Transport Package: Standard Exporting Packing Origin: China

Basic Features of Spherical Plain Bearing
Types	Radial Spherical Plain Bearings Steel ball dimensions Oil cylinder earrings Spherical Plain Bearings Spherical Plain Bearings Rod End L-Ball Joint Rod End Angular Contact Spherical Plain Bearings Thrust Spherical Plain Bearings ШC∏ Series
Material	Bearing Steel(GCr15, 100Cr6) Carbon Steel Stainless Steel Bronze
Dimension	Metric and Inch
Surface treatment	Phosphated Sliding surface treated with MoS2 Sliding surface treated with Chromium plating Sliding surface of PTFE Composite Material Sliding surface of PTFE Fabric
Series and bore diameter range	GE...E  4~12mm GE...ES  15~200mm GE...ES-2RS  15~200mm GEG...E  4~12mm GEG...ES  15~200mm GEG...ES-2RS  15~200mm SB...A  12~150mm GEEW...ES  12~160mm GEEM...ES-2RS  20~80mm GEZ...ES  12.7~152.4mm GEZ...ES-2RS  19.05~152.4mm GEWZ...ES  12.7~88.9mm GEWZ...ES-2RS  19.05~88.9mm GEGZ...ES  31.75~139.7mm GEGZ...ES-2RS  31.75~139.7mm GEBK...S  5~30mm GE......C  4~30mm GEG...C  4~30mm SGE..C  4~30mm SGEG...C  4~30mm COM  4.83~25.4mm COM...T  4.83~25.4mm GE...ET-2RS  15~120mm GEG...ET-2RS  15~120mm GEZ...ET-2RS  19.05~152.4mm GK...DO 10-80mm GF...DO  20~80mm GIHR-K...DO  20~100mm GIHN...K-LO  12-80mm GAC...S  25~200mm GX...S  10~200mm
MOQ	1 PC
Delivery Time	20-45 days
Sea Ports	Shanghai Ningbo Qingdao

Why Choose HECTO?
1. More than 20 years of manufacturing and exporting experiences
2. an ISO/TS16949 company
3. 100% inspecting of products
4. More competitive prices with better quality
5. More than 99% of delivery in time
6. Rapid response of your emails and questions
7. Products can be traced back


Spherical Plain Bearings of GE...E, GE...ES, GE...ES-2RS series

Bearing No.		Dimensions(mm)								Load Ratings		Weight
		d	D	B	C	dk	rs min	r1s min	α	Dynamic	Static
										(KN)	(KN)	(Kg)
GE4E		4	12	5	3	8	0.3	0.3	16	2	10	0.003
GE5E		5	14	6	4	10	0.3	0.3	13	3.4	17	0.005
GE6E		6	14	6	4	10	0.3	0.3	13	3.4	17	0.004
GE8E		8	16	8	5	13	0.3	0.3	15	5.5	27	0.008
GE10E		10	19	9	6	16	0.3	0.3	12	8.1	40	0.011
GE12E		12	22	10	7	18	0.3	0.3	10	10	53	0.015
GE15ES	GE15ES-2RS	15	26	12	9	22	0.3	0.3	8	16	84	0.027
GE17ES	GE17ES-2RS	17	30	14	10	25	0.3	0.3	10	21	106	0.041
GE20ES	GE20ES-2RS	20	35	16	12	29	0.3	0.3	9	30	146	0.066
GE25ES	GE25ES-2RS	25	42	20	16	35.5	0.6	0.6	7	48	240	0.119
GE30ES	GE30ES-2RS	30	47	22	18	40.7	0.6	0.6	6	62	310	0.153
GE35ES	GE35ES-2RS	35	55	25	20	47	0.6	1	6	79	399	0.233
GE40ES	GE40ES-2RS	40	62	28	22	53	0.6	1	7	99	495	0.306
GE45ES	GE45ES-2RS	45	68	32	25	60	0.6	1	7	127	637	0.427
GE50ES	GE50ES-2RS	50	75	35	28	66	0.6	1	6	156	780	0.546
GE60ES	GE60ES-2RS	60	90	44	36	80	1	1	6	245	1220	1.04
GE70ES	GE70ES-2RS	70	105	49	40	92	1	1	6	313	1560	1.55
GE80ES	GE80ES-2RS	80	120	55	45	105	1	1	6	400	2000	2.31
GE90ES	GE90ES-2RS	90	130	60	50	115	1	1	5	488	2440	2.75
GE100ES	GE100ES-2RS	100	150	70	55	130	1	1	7	607	3030	4.45
GE110ES	GE110ES-2RS	110	160	70	55	140	1	1	6	654	3270	4.82
GE120ES	GE120ES-2RS	120	180	85	70	160	1	1	6	950	4750	8.05
GE140ES	GE140ES-2RS	140	210	90	70	180	1	1	7	1070	5350	11.02
GE160ES	GE160ES-2RS	160	230	105	80	200	1	1	8	1360	6800	14.01
GE180ES	GE180ES-2RS	180	260	105	80	225	1.1	1.1	6	1530	7650	18.65
GE200ES	GE200ES-2RS	200	290	130	100	250	1.1	1.1	7	2120	10600	28.03

Contact us if you need more details on Spherical Plain Bearing. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Joint Bearing、Knuckle Bearing. If these products fail to match your need, please contact us and we would like to provide relevant information.
