Needle Roller Bearing Combined Bearing Drawn Cup Thrust Rax 715

Basic Info

Model No.:  RAX715

Product Description

Model NO.: RAX715 Rows Number: Single Style: Without Outer Ring, Without Inner Ring Type: Closed Lubrication: Oil or Grease Rolling Body: Roller Bearings Spherical: Non-Aligning Bearings Trademark: HECTO or OEM or neutral marking or no marking Origin: China Cage: With Cage Load Direction: Radial Bearing Material: Bearing Steel Needle Super Finishing: Yes Precision: P0 P5 P6 The Number of Rows: Single Separated: Unseparated Specification: 15*31.5*14.2mm HS Code: 84824000
Basic Features of Combined Bearing
Types RAX...  series
Material Bearing Steel(GCr15, 100Cr6)
SPCC St14
Nylon
Dimension Metric and Inch
Dimension Range 3mm~80mm(bore diameter)
MOQ 1
Delivery Time 15-45 days
Sea Ports Shanghai Ningbo Qingdao


Why Choose HECTO?
1. More than 20 years of manufacturing and exporting experiences
2. an ISO/TS16949 company
3. 100% inspecting of products
4. More competitive prices with better quality
5. More than 99% of delivery in time
6. Rapid response of your emails and questions
7. Products can be traced back
Needle Roller Bearing Combined Bearing Drawn Cup Thrust Rax 715
Needle Roller Bearing Combined Bearing Drawn Cup Thrust Rax 715
Combined Bearing RAX... series
Bearing No.
Inner Outer D1 Outer D2 Length C dyn r Co stat r C dyn a Co stat a C lim r C lim a Nominal Speed Weight
(mm) (mm) (mm) (mm) (N) (N) (N) (N) (N) (N) (tr/min) (g)
RAX 705 5 9 15.5 11 2150 1950 3150 6350 740 3500 25000 4.5
RAX 712 12 18 27.5 14.2 6300 7200 6900 17700 2500 11000 13000 16.5
RAX 714 14 20 29.5 14.2 6900 8500 7400 20000 2900 12500 11500 18
RAX 715 15 21 31.5 14.2 7400 9300 7800 22000 3100 14000 10500 20
RAX 718 18 24 33.5 18.2 11500 17700 8000 23000 5800 16000 10000 27
RAX 720 20 26 36.5 18.2 12200 19500 11800 39000 6400 18000 9000 31
RAX 725 25 33 45.5 22.2 20500 32000 13700 52000 10500 22000 7200 55
RAX 730 30 38 50.5 22.2 22300 37500 14900 60000 12000 25000 6300 63
RAX 735 35 43 56.5 22.2 24500 45000 19400 88000 14300 27000 5500 75
RAX 740 40 48 61.5 22.2 26200 51000 20400 96000 16000 30000 5000 86
RAX 745 45 52 66.5 22.2 24800 55000 21800 109000 17000 32000 4500 88

Contact us if you need more details on Needle Bearing. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Needle and Cage Assemblies、Drawn Cup Needle Bearing. If these products fail to match your need, please contact us and we would like to provide relevant information.
